Zoomtel 4650 - LTE Cat M1 & Cat NB1 Industrial USB Cell Modem
← Back to store

Zoom Telephonics 4650 Cat M1 Dongle

$80.00 USD

Type

Description

Featuring high-performance RF, antenna, and power supply design, this AT&T® certified LTE Cat M1 USB modem is the right choice for many M2M and IoT product designs. The modems’ extensive certifications dramatically lower the costs, time to market, and risk associated with incorporating a cellular modem module into your device. LTE Cat M1 capability helps assure long-term “future proof” compatibility with the AT&T cellular network. Also available at Amazon.com.



Features

  • Includes Quectel® modules with high performance and guaranteed availability for many years
  • Flexible power handling – supplied by the primary USB port
  • SMA and U.FL antenna options allow fixed or moveable antennas
  • Works with Linux, Mac, Windows, and Raspberry Pi devices
  • Operating free-air temperature: -30° to 60° C
  • Built-in Protocol Stack – transparent and non-transparent TCP/UDP client and server
  • Built-in SIM connector with auto-detect feature
  • On-board Java can execute from non-volatile memory
  • Two LEDs
  • Flexible USB modem mounting – plugs directly into the USB port or indirectly via USB cable

Technical Specifications

Module

Quectel BG96

Carrier Certification

AT&T, PTCRB (Module & Device), GCF-certified module

Antenna Option

SMA

Maximum speed

375 kbps DL / 375 kbps UL

Compliance

FCC Part 15B, 15C (Module), ISED, US/CA ITE Safety, CE

Supplemental Power Connector

USB Micro-B receptacle

Frequency Bands

B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B26/B28/B39

Dimensions (including SMA and USB connectors)

80.9 mm L x 43.4 mm W x 15 mm



For additional information, please see the Zoomtel LTE Cat M1 USB modem product description document.
