Soracom Onyx LTE™ USB Modem

Soracom Onyx LTE™ USB Modem

A pre-certified USB cellular modem for global connectivity on LTE Cat.4, 3G, and 2G networks.

Soracom Onyx LTE USB Modem Soracom Onyx LTE USB Modem

Connect Linux Devices Over Cellular

Soracom Onyx LTE™ USB Cellular Modem is a high-performance communications device allowing cellular data connectivity for fixed and mobile applications.

Connect Almost ANY Device Over Cellular with Soracom's Onyx

Add Cellular Data to a Gateway or Smart Device Over USB

Soracom Onyx LTE™ USB Cellular Modem is a high-performance communications device allowing cellular data connectivity for fixed and mobile applications.

Built for IoT and M2M applications

The Soracom Onyx provides a Quectel® EG25-G LTE Cat. 4 module, which features global 4G/LTE, 3G, and 2G cellular connectivity and is optimized specifically for IoT and M2M applications.

Integrates a modem and antenna, powered by the USB port

This means no extra accessories nor power supply are required to get the host device online. Two CRC9 connectors also allow external antenna connection. In a bad radio environment, you may extend out cables and place antennas away from the host device for better connectivity.

Connected by the powerful Soracom Global IoT SIM

The embedded modem features Soracom’s LTE band coverage and radio certifications for global use, providing connectivity almost anywhere in the world right out of the box.

Just Plug It In And Start Coding

We designed the Soracom Onyx to make it as quick and simple as possible to start developing connected products. It’s perfect for whether you’re building a prototype, or if you’re scaling your IoT tech out to thousands of different devices.

Insert the Soracom Onyx

Insert the Soracom Onyx

Plug the Soracom Onyx LTE USB hardware into any Linux host device with a USB slot.

Soracom Onyx Technical Specs
Start Prototyping

Start Prototyping

Your device will instantly have access to LTE band coverage and radio certifications for global use.

View Developer Docs
✅ Global IoT Coverage
✅ Optimised for IoT & M2M
✅ Compact, Rugged Design
✅ Built-in Antenna
✅ AT Command Support
✅ Host-Powered USB

Soracom Onyx Connectivity Kits

Includes bundled monthly IoT data coverage

The Soracom Onyx Connectivity Kits are packaged with a Soracom IoT SIM, providing 100MB, 500MB, or 1GB of monthly data, access to Soracom’s User Console for SIM management and monitoring, and several of Soracom’s powerful platform features.

With the first 12 months of our planX3-EU service included, these connectivity kits provide everything you need to get started with cellular IoT in a cost-effective way, without the need to check SIM compatibility, coverage, or complicated pricing.

Soracom Onyx Connectivity Kits Features

  • 1x Soracom Onyx LTE™ USB Modem
  • 1x Soracom Air planX3-EU SIM card (3-in-1), with the first 12 months of services included
  • 100MB, 500MB, or 1GB monthly bundled data, depending on connectivity kit
  • Soracom User Console and SIM management features (Event Handler, Billing Alerts, IMEI Lock, etc.)
  • Soracom platform services, including data handling, remote device access, packet capture, and more.
  • Availability: Finland, France, Germany, Italy, Lithuania, Sweden, Switzerland, United Kingdom
  • Coverage: Over 70 mobile networks across 37 European countries (please check here for the latest coverage information)
Insert the Soracom Onyx

The easiest way of adding cellular IoT connectivity to devices that don’t feature a SIM card slot.

This means no extra accessories nor power supply are required to get the host device online. Two CRC9 connectors also allow external antenna connection. In a bad radio environment, you may extend out cables and place antennas away from the host device for better connectivity.

The device satisfies all network & RF requirements for cellular connectivity by itself, which makes it radio-certified as an end product. By using the Onyx LTE™ USB hardware, you can avoid getting additional radio certifications and immediately deploy your IoT system in the field.

The embedded modem features global LTE band coverage and radio certifications for global use. This single SKU + our global SIM can provide connectivity almost anywhere in the world, without having to modify the system.Learn More About The Soracom IoT SIM

The built-in application protocols such as TCP, UDP, PPP, FTP, HTTP, and MQTT allow devices to integrate into various system architectures and cloud services quickly without the need for custom code.

Over 20,000 businesses around the world rely on Soracom for secure IoT connectivity.

Read our customer stories
Sharp Sharp Sharp Sharp Sharp Sharp

Soracom Onyx – Pricing

Starting at
per device
Buy Now

Available Via Our Approved Distributors

The Soracom Onyx is available to purchase in North America exclusively via our approved distributors, DigiKey and Mouser. Need help? Please get in touch with our team.

Connect With Us

Price Includes Monthly Cellular Connectivity

Monthly Data Bundle Size Price
Soracom Onyx 100MB Europe
Soracom Onyx 500MB Europe
Soracom Onyx 1GB Europe
USB interface
4G/3G/2G Technology
Status LED
Cloud Agnostic

Soracom Onyx – Technical Specifications

Connectivity Modem EG25-G
Region Global
Performance LTE Cat. 4 (3GPP Release 11)
Network Bands LTE-FDD B1 / B2/ B3 / B4 / B5 / B7 / B8 / B12 / B13 / B18 / B19 / B20 / B25 / B26 / B28
LTE-TDD B38/B39/B40/B41
UMTS B1/B2/B4/B5/B6/B8/B19
GSM 850/900/1800/1900
Packet Data Max. 150Mbps downlink / Max. 50Mbps uplink
Application Compatibility 3GPP TS 27.007, TS 27.005, Enhanced AT Commands
Protocols TCP, UDP, PPP, FTP, HTTP, MQTT, NTP, NITZ, PING, QMI
Messaging SMS, USSD
Operating Systems Linux 2.6 ~ 5.4
Interfaces USB USB 2.0 Type A
Antenna Built-in, 2 × CRC9
Power Operating Voltage USB powered, 4.2V ~ 6.0V
Power Consumption 35mA (idle, typical), 600mA (during communication, typical)
Physical Dimensions 95mm × 36mm × 13mm
Weight 36g
Casing PC-ABS
Temperature Range -20°C ~ 60°C (operation), -35°C ~ 85°C (storage)
Humidity 5% ~ 75% (operation, non-condensing), Max. 80% (storage, non-condensing)
Certs Regulatory FCC, PTCRB, JATE, TELEC, CE, UKCA, KC
Safety RoHS
Soracom Onyx Technical Specifications
